TRACOPOWER THN 20-2423WI Isolated Board Mount DC/DC Converter, Compact, 2 Output, 20 W, 15 V, 667 mA, -15 V, 667 mA

This is a Isolated Board Mount DC/DC Converter, Compact, 2 Output, 20 W, 15 V, 667 mA, -15 V, 667 mA product from TRACOPOWER with the model number THN 20-2423WI

Product details

No. of Outputs	2 Output
Output Power Max	20W
Output Voltage - Output 1	15V
Output Current - Output 1	667mA
Output Voltage - Output 2	-15V
Output Current - Output 2	667mA
Output Voltage - Output 3	-
Output Current - Output 3	-
Product Range	THN 20WI Series
Input Voltage DC Min	9V
Input Voltage DC Max	36V
DC / DC Converter Output Type	Fixed, Adjustable
DC / DC Converter Type	DIP
DC / DC Converter Mounting	Through Hole
Approvals & Standards	UL
Width	25.4mm
Height	9.9mm
Depth	25.4mm

Other details

Brand	TRACOPOWER
Part Number	THN 20-2423WI
Quantity	Each
