| ₹ 5540.52 includes GST and import duties. | |
| B2B customers can avail ₹ 844.93 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
This is a Isolated Board Mount DC/DC Converter, Metal Case, 1 Output, 20 W, 5 V, 4 A product from TRACOPOWER with the model number THN 20-2411
Product details
| No. of Outputs | 1 Output |
| Output Power Max | 20W |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 1 | 4A |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | THN 20 Series |
| Input Voltage DC Min | 18V |
| Input Voltage DC Max | 36V |
| DC / DC Converter Output Type | Fixed, Adjustable |
| DC / DC Converter Type | DIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | IEC, UL |
| Width | 25.4mm |
| Height | 9.9mm |
| Depth | 25.4mm |
Other details
| Brand | TRACOPOWER |
| Part Number | THN 20-2411 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 5429.71 |
| 3-5 | ₹ 5374.3 |
| 5-10 | ₹ 5263.49 |
| 10+ | ₹ 5152.68 |
Bulk discount will be automatically applied during checkout based on quantity.
