| ₹ 4986.0 includes GST and import duties. | |
| B2B customers can avail ₹ 760.37 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The THN 15-2411WI from Tracopower is a single output, isolated, 15W DC to DC converter. This module comes with an encapsulated, shielded metal package with dimensions of only 1.0"x 1.0"x 0.4" and occupies 50% less board space. THN 15-2411WI has an ultra wide 4:1 input voltage range and precisely regulated output voltage. The module functions with remote On/Off and trimmable output. Typical applications for these converters are battery operated equipment, mobile instrumentation, distributed power architectures and everywhere where space on PCB is critical.
- Input voltage range from 9VDC to 36VDC
- Output voltage is 5VDC
- Output current is 3A
- Typical efficiency is 86%
- I/O isolation is 1.5KVDC
- Operating temperature range from -40�C to 85�C
- Output voltage trim capability
- Industry standard pin-out
- UL /cUL 60950-1, EN 60950-1, IEC 60950-1 safety standards
Applications
Industrial, Power Management
Product details
| Output Power Max | 15W |
| Input Voltage DC Min | 9V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 25.4mm |
| Width | 25.4mm |
| Product Range | - |
| DC / DC Converter Type | DIP |
| Approvals & Standards | IEC, UL |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 3A |
| Height | 9.9mm |
Other details
| Brand | TRACOPOWER |
| Part Number | THN 15-2411WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 4886.28 |
| 3-5 | ₹ 4836.42 |
| 5-10 | ₹ 4736.7 |
| 10+ | ₹ 4636.98 |
Bulk discount will be automatically applied during checkout based on quantity.
