| ₹ 5535.79 includes GST and import duties. | |
| B2B customers can avail ₹ 844.21 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
This is a Isolated Board Mount DC/DC Converter, Metal Case, 2 Output, 12 W, 15 V, 400 mA, -15 V, 400 mA product from TRACOPOWER with the model number THD 12-2423WI
Product details
| Output Power Max | 12W |
| Input Voltage DC Min | 9V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 400mA |
| Depth | 32mm |
| Width | 20.3mm |
| Product Range | THD12WI Series |
| DC / DC Converter Type | DIP |
| Approvals & Standards | IEC, UL |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 3 | - |
| No. of Outputs | 2 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 400mA |
| Height | 10.2mm |
Other details
| Brand | TRACOPOWER |
| Part Number | THD 12-2423WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 5425.07 |
| 3-5 | ₹ 5369.72 |
| 5-10 | ₹ 5259.0 |
| 10+ | ₹ 5148.28 |
Bulk discount will be automatically applied during checkout based on quantity.
