The TES 1-0513 is a 1-output board-mount isolated DC to DC Converter with small footprint. The TES 1 series 1W DC/DC converter is an ideal and economical solution for many applications where an isolated voltage is required. Typical applications are ground loop elimination, noise reduction, voltage isolation in digital interfaces and voltage conversion in distributed power systems. This converter is qualified for the higher temperatures requested by lead-free reflow solder processes.
- Standard footprint
- 1500VDC I/O Isolation
- High efficiency up to 80%
- High accuracy of pin co-planarity
- -40 to +90°C Operating temperature range
Applications
Power Management
Product details
| No. of Outputs |
1 Output |
| Output Power Max |
1W |
| Output Voltage - Output 1 |
15V |
| Output Current - Output 1 |
65mA |
| Output Voltage - Output 2 |
- |
| Output Current - Output 2 |
- |
| Output Voltage - Output 3 |
- |
| Output Current - Output 3 |
- |
| Product Range |
- |
| Input Voltage DC Min |
4.5V |
| Input Voltage DC Max |
5.5V |
| DC / DC Converter Output Type |
Fixed |
| DC / DC Converter Type |
Surface Mount DIP |
| DC / DC Converter Mounting |
Surface Mount Device |
| Width |
8mm |
| Height |
7mm |
| Depth |
16.3mm |
| RoHS Phthalates Compliant |
Yes |
Other details
| Brand |
TRACOPOWER |
| Part Number |
TES 1-0513 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
| Application Note EN |
|
| Miscellaneous EN |
|
