Description
The TEP 75-2412WI is a 1-output DC to DC Converter with ultra wide 4:1 input voltage ranges. The TEP-75WI series 75W isolated high performance DC/DC converter module is suitable for a wide range of applications, but the product is designed particularly also for industrial applications where often no PCB mounting is possible but the module has to be mounted on a chassis. Four threaded M3 inserts in the module makes chassis mount or attachment of a heatsink for optimal thermal management very simple. For easy connection there is also a unique adaptor available with screw terminals. A very high efficiency allows an operating temperature up to +60°C with natural convection cooling without power derating. The very wide input voltage range and reverse input voltage protection make this converter also an interesting solution for battery operated systems.
- Rugged, compact metal case
- EN 50155 approval for railway applications
- Output voltage trimming
- Remote on/off
- Under-voltage lockout
- Reverse input voltage protection
- Input protection filter
Applications
Power Management, Industrial
Product details
| Output Power Max | 75W |
| Input Voltage DC Min | 9V |
| DC / DC Converter Mounting | Chassis |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Product Range | TEP 75WI Series |
| Approvals & Standards | IEC, UL |
| Output Voltage - Output 1 | 12V |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 6.3A |
Other details
| Brand | TRACOPOWER |
| Part Number | TEP 75-2412WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 14545.6 |
| 3-5 | ₹ 14397.18 |
| 5-10 | ₹ 14100.33 |
| 10+ | ₹ 13803.48 |
Bulk discount will be automatically applied during checkout based on quantity.
