Description
The TEN 6-2411WIN is a 1-output board-mount Isolated DC/DC Converter features wide input voltage ranges of 9 to 36VDC. A high efficiency allows a wide operating temperature range of -40 to +85�C. It provides over voltage protection and short-circuit protection. It is also a drop in replacement for many cost critical applications.
- Wide 4:1 input range
- 80% Efficiency
- 1500VDC I/O isolation
- �0.02%/K Temperature coefficient
- 470�F Maximum capacitive load
- 330kHz Switching frequency
- Input filter meets EN 55022, class A
- No minimum load required
Applications
Power Management
Product details
| Output Power Max | 6W |
| Input Voltage DC Min | 9V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 31.8mm |
| Width | 20.3mm |
| Product Range | - |
| DC / DC Converter Type | DIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 1.2A |
| Height | 10.2mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEN 6-2411WIN |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Application Note EN | |
