TRACOPOWER TEN 5-4821WI Isolated Board Mount DC/DC Converter, 4:1 Input, Fixed, 2 Output, 18 V, 75 V, 5 W, 5 V

This is a Isolated Board Mount DC/DC Converter, 4:1 Input, Fixed, 2 Output, 18 V, 75 V, 5 W, 5 V product from TRACOPOWER with the model number TEN 5-4821WI

Product details

Output Power Max	5W
Input Voltage DC Min	18V
DC / DC Converter Mounting	Through Hole
Output Voltage - Output 2	-5V
Output Current - Output 2	500mA
Depth	31.8mm
Width	20.3mm
Product Range	TEN 5WI Series
DC / DC Converter Type	DIP
Approvals & Standards	IEC, UL
Output Voltage - Output 3	-
Output Voltage - Output 1	5V
Output Current - Output 3	-
No. of Outputs	2 Output
DC / DC Converter Output Type	Fixed
Input Voltage DC Max	75V
Output Current - Output 1	500mA
Height	10.2mm

Other details

Brand	TRACOPOWER
Part Number	TEN 5-4821WI
Quantity	Each
Technical Data Sheet EN
Miscellaneous EN
