TRACOPOWER TEN 5-1221 Isolated Board Mount DC/DC Converter, 2 Output, 6 W, 5 V, 500 mA, -5 V, 500 mA

This is a Isolated Board Mount DC/DC Converter, 2 Output, 6 W, 5 V, 500 mA, -5 V, 500 mA product from TRACOPOWER with the model number TEN 5-1221

Product details

No. of Outputs	2 Output
Output Power Max	6W
Output Voltage - Output 1	5V
Output Current - Output 1	500mA
Output Voltage - Output 2	-5V
Output Current - Output 2	500mA
Output Voltage - Output 3	-
Output Current - Output 3	-
Product Range	TEN 5 Series
Input Voltage DC Min	9V
Input Voltage DC Max	18V
DC / DC Converter Output Type	Fixed
DC / DC Converter Type	DIP
DC / DC Converter Mounting	Through Hole
Approvals & Standards	-
Width	20.3mm
Height	10.2mm
Depth	31.8mm

Other details

Brand	TRACOPOWER
Part Number	TEN 5-1221
Quantity	Each
Technical Data Sheet EN
