Description
The TEN 40-2415WIR is a 1-output board-mount isolated DC to DC Converter with adjustable output voltage and ultra wide 4:1 input voltage range. The TEN 40WIR series 40W converter offers over voltage protection and short-circuit protection. Low input current characteristics at minimal load make this converter the ideal solution for battery-operated systems.
- EN 50155 approval for railway applications
- Thermal shock and vibration resistant according EN 61373
- High efficiency up to 92%
- No minimum load required
- Under-voltage lockout circuit
- Remote on/off
- -40 to +85�C Operating temperature range
Applications
Wireless, Test & Measurement, Industrial
Product details
| Output Power Max | 40W |
| Input Voltage DC Min | 9V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 50.8mm |
| Width | 25.4mm |
| Product Range | - |
| DC / DC Converter Type | DIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 24V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed, Adjustable |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 1.666A |
| Height | 10.2mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEN 40-2415WIR |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Application Note EN | |
