| ₹ 10459.79 includes GST and import duties. | |
| B2B customers can avail ₹ 1595.12 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
This is a Isolated Board Mount DC/DC Converter, Metal Case, 3 Output, 30 W, 5 V, 4 A, 12 V, 420 mA product from TRACOPOWER with the model number TEN 30-2431WIN
Product details
| No. of Outputs | 3 Output |
| Output Power Max | 30W |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 1 | 4A |
| Output Voltage - Output 2 | 12V |
| Output Current - Output 2 | 420mA |
| Output Voltage - Output 3 | -12V |
| Output Current - Output 3 | 420mA |
| Product Range | - |
| Input Voltage DC Min | 9V |
| Input Voltage DC Max | 36V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | DIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | - |
| Width | 25.4mm |
| Height | 10.2mm |
| Depth | 50.8mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEN 30-2431WIN |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 10250.59 |
| 3-5 | ₹ 10146.0 |
| 5-10 | ₹ 9936.8 |
| 10+ | ₹ 9727.6 |
Bulk discount will be automatically applied during checkout based on quantity.
