Description
The TEN 3-2423 is a 2-output board-mount Isolated DC/DC Converter. It features ultra wide input voltage ranges of 18 to 36VDC. A high efficiency allows a wide operating temperature range of -40 to +85°C. It provides over voltage protection and short-circuit protection.
- Wide 2:1 input range
- 82% Efficiency
- 1500VDC I/O isolation
- ±0.02%/K Temperature coefficient
- 1000µF Maximum capacitive load
- 300kHz Switching frequency
- Full SMD design
- High reliability
Applications
Industrial, Communications & Networking
Product details
| Output Power Max | 3W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 100mA |
| Depth | 32mm |
| Width | 20.3mm |
| Product Range | - |
| DC / DC Converter Type | DIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 3 | - |
| No. of Outputs | 2 Output |
| DC / DC Converter Output Type | Fixed, Adjustable |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 100mA |
| Height | 10.2mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEN 3-2423 |
| Quantity | Each |
| Technical Data Sheet EN |  |
