Description
The TEN 15-2411WI is a 1-output board-mount isolated DC to DC Converter with ultra-wide 4:1 input range. The TEN 15WI series converter offers high efficiency and indefinite short circuit protection. Full SMD-design with use of ceramic chip capacitors guarantees a high reliability and a long lifetime.
- High efficiency up to 86%
- 1500VDC I/O Isolation
- Built-in filter to meet EN 55022, class A and FCC, level A without external components
- Remote on/off
- Industry standard pinout
- Six-side shielded case
- -40 to +85°C Operating temperature range
Applications
Power Management, Communications & Networking, Industrial
- :
- 15W
- :
- 9V
- :
- Through Hole
- :
- -
- :
- -
- :
- 50.8mm
- :
- 25.4mm
- :
- -
- :
- DIP
- :
- CSA, IEC, UL
- :
- -
- :
- 5.1V
- :
- -
- :
- 1 Output
- :
- Fixed
- :
- 36V
- :
- 2.95A
- :
- 10.2mm
Product details
| Output Power Max | 15W |
| Input Voltage DC Min | 9V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 50.8mm |
| Width | 25.4mm |
| Product Range | - |
| DC / DC Converter Type | DIP |
| Approvals & Standards | CSA, IEC, UL |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 5.1V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 2.95A |
| Height | 10.2mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEN 15-2411WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
