TRACOPOWER TEN 10-1215 Isolated Board Mount DC/DC Converter, High Power Density, Fixed, 1 Output, 9 V, 18 V, 10 W, 24 V

This is a Isolated Board Mount DC/DC Converter, High Power Density, Fixed, 1 Output, 9 V, 18 V, 10 W, 24 V product from TRACOPOWER with the model number TEN 10-1215

Product details

Output Power Max	10W
Input Voltage DC Min	9V
DC / DC Converter Mounting	Through Hole
Output Voltage - Output 2	-
Output Current - Output 2	-
Depth	50.8mm
Width	25.4mm
Product Range	TEN 10 Series
DC / DC Converter Type	DIP
Approvals & Standards	-
Output Voltage - Output 3	-
Output Voltage - Output 1	24V
Output Current - Output 3	-
No. of Outputs	1 Output
DC / DC Converter Output Type	Fixed
Input Voltage DC Max	18V
Output Current - Output 1	415mA
Height	10.2mm

Other details

Brand	TRACOPOWER
Part Number	TEN 10-1215
Quantity	Each
