Description
This is a Isolated Board Mount DC/DC Converter, Regulated, Through Hole, 3W, 15V, 100mA, -15V, 100mA product from TRACOPOWER with the model number TEM 3-0523N
Product details
| Output Power Max | 3W |
| Input Voltage DC Min | 4.5V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 100mA |
| Depth | 32mm |
| Width | 20mm |
| Product Range | TEM 3N Series |
| DC / DC Converter Type | DIP |
| Approvals & Standards | CSA, IEC, UL |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 3 | - |
| No. of Outputs | 2 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 5.5V |
| Output Current - Output 1 | 100mA |
| Height | 10mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEM 3-0523N |
| Quantity | Each |
| Technical Data Sheet EN |  |
