Description
The TEL 3-2423 is a 2-output board-mount Isolated DC/DC Converter features ultra wide input voltage ranges of 18 to 36VDC. A high efficiency allows operation temperature up to +71�C at full load and low output noise.
- Wide 2:1 and 3:1 input range
- 81% Efficiency
- 1500VDC I/O isolation
- �0.02%/K Temperature coefficient
- 1000�F Maximum capacitive load
- 300kHz Switching frequency
- Indefinite short-circuit protection
Applications
Industrial, Consumer Electronics
Product details
| Output Power Max | 3W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 100mA |
| Depth | 32mm |
| Width | 20mm |
| Product Range | TEL 3 Series |
| DC / DC Converter Type | DIP |
| Approvals & Standards | CSA, IEC, UL |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 3 | - |
| No. of Outputs | 2 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 100mA |
| Height | 10.2mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEL 3-2423 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
