Description
TP-Link TL-SG3452 Overview
- 1Description
- 2Centralized Management
- 3L2+ and L3 Support
- 4Security Features
- 5Enterprise Level Features
- 6Advanced QoS
- 7ISP Features
- 8IPv6 Support
- 9Silent Cooling
Expand your office or business network capacity to handle a multitude of high-bandwidth applications with the JetStream TL-SG3452 48-Port Gigabit Managed Switch from TP-Link. This managed rack-mountable switch features 48 Gigabit Ethernet ports to that allow you to connect computers, NAS systems, servers, and other compatible devices to your network. There are also four Gigabit SFP ports for high-speed fiber uplinks.
With its 104 Gb/s switching capacity and 77.4 Mpps forwarding rate, the TL-SG3452 provides smooth data transfers. The broad range of L2+ and L3 features allow you to configure and manage your network to best suit your business's needs. A host of security features includes an Access Control List (ACL), Storm Control, and DHCP Snooping to help defend your network against threats. Use the Omada Software Defined Networking platform to manage your connected network devices remotely with the Omada app.
Centralized Management
The Omada Software Defined Networking (SDN) platform integrates access points, switches, gateways, and other network devices to provide high efficiency, security, and reliability. Configure, manage, and monitor your network using a single interface, from almost anywhere in the world, through the cloud portal interface and Omada smartphone and tablet app.
L2+ and L3 Support
Extensive L2+ and L3 features help to build a highly scalable and robust network for businesses, campuses, and ISPs.
Note:
ISP L3 features can only be configured in standalone mode.
Security Features
Protect your network from attacks and intrusions with IP-MAC-Port-VID Binding, Access Control List, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, VLAN ID, and more.
Enterprise Level Features
The complete lineup of L2+ features includes 802.1Q VLAN, Port Mirroring, Link Aggregation Control Protocol, and 802.3x Flow Control.
Advanced QoS
Voice and video traffic can be prioritized based on IP address, MAC address, TCP port number, UDP port number, and more to help ensure smooth broadcasts and clear calls, even when bandwidth is limited.
ISP Features
sFlow, QinQ, L2PT PPPoE ID Insertion, and IGMP authentication features are included with service providers in mind. 802.3ah OAM and Device Link Detection Protocol (DLDP) offer easy monitoring and troubleshooting of Ethernet links.
Note:
ISP features can only be configured in standalone mode.
IPv6 Support
IPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery, and IPv6 Neighbor Discover help to ensure that your network is ready for the Next Generation Network (NGN) without having to upgrade your hardware.
Silent Cooling
The fanless design provides passive cooling to the switch while maintaining a quiet environment.
UPC: 845973010164
In the Box
- TP-Link JetStream TL-SG3452 48-Port Gigabit Managed Switch with SFP
- Power Cable
- Rackmount Kit
- Rubber Feet
- Limited Lifetime Warranty
Table of Contents
- Description
- Centralized Management
- L2+ and L3 Support
- Security Features
- Enterprise Level Features
- Advanced QoS
- ISP Features
- IPv6 Support
- Silent Cooling
TP-Link TL-SG3452 Specs
Interfaces
| Inputs/Outputs | 48 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) 4 x 10/100/1000 Mb/s Gigabit SFP (Uplink) 1 x Ethernet (RJ45) (Console) 1 x Micro-USB (Console) |
Protocols
| Layer Services Supported | Layer 2 Support, Layer 3 Support |
| Supported Protocols | Auto-MDIX/MDI IGMP Snooping IPv4 IPv6 Link Aggregation Port Mirroring SNMPv1 SNMPv2c SNMPv3 |
| Queuing | Strict Priority, Weighted Round Robin (WRR) |
| Jumbo Frames Support | 9000 Bytes |
| MAC Address Table Size | 16K |
| Multicast Groups | 256 |
Security
| Security Features | DHCP Snooping DoS Attack Prevention RADIUS Authentication Storm Control |
| Static Routes | 48 |
| SNMP Support | 1, 2c, 3 |
Standards
| RFC | RFC 1757 |
| Supported IEEE Standards | 802.1ab, 802.1d, 802.1p, 802.1q, 802.1s, 802.1w, 802.1x, 802.3ad, 802.3x |
Performance
| Forwarding Rate | 77.4 Mpps |
| Switching Bandwidth | 104 Gb/s |
| Priority Queues | 8 |
| Packet Buffer | 12 Mb |
Electrical
| Power Draw | 32.8 W (Max) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Supply Type | Internal |
Environmental
| Operating Temperature | 32 to 113°F / 0 to 45°C |
| Operating Humidity | 10 to 90% |
| Storage Temperature | -40 to 158°F / -40 to 70°C |
| Storage Humidity | 5 to 90% |
General
| Certifications | CE, FCC, RoHS *as per Manufacturer |
| Cooling System | Passive |
| Rack Form Factor | 1 RU |
| Dimensions | 17.3 x 8.7 x 1.7" / 440 x 220 x 44 mm |
Packaging Info
| Package Weight | 9.17 lb |
| Box Dimensions (LxWxH) | 21.2 x 13.2 x 3.8" |
