| ₹ 643.6 includes GST and import duties. | |
| B2B customers can avail ₹ 98.15 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The TPS7A3001DRBT is a negative high-voltage ultralow-noise Linear Regulator that can source a maximum load of 200mA. This device includes a CMOS logic-level-compatible enable pin and capacitor-programmable soft-start function that allows for customized power-management schemes. Other features include built-in current limit and thermal shutdown protection to safeguard the device and system during fault conditions. It is designed using bipolar technology and is ideal for high-accuracy, high-precision instrumentation applications where clean voltage rails are critical to maximize system performance. This design makes the device an excellent choice to power operational amplifiers, analog-to-digital converters, digital-to-analog converters and other high-performance analog circuitry. The device is suitable for post DC-DC converter regulation. By filtering out the output voltage ripple inherent to DC-DC switching conversion, maximum system performance is provided in many applications.
- CMOS logic-level-compatible enable pin
- Power-supply ripple rejection - 72dB (120Hz) and >=55dB (10Hz to 700kHz)
- Green product and no Sb/Br
Sensing & Instrumentation, Test & Measurement, Audio, RF Communications
Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | TPS7A3001DRBT |
| Quantity | Each (Supplied on Cut Tape) |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 630.73 |
| 3-5 | ₹ 624.29 |
| 5-10 | ₹ 611.42 |
| 10+ | ₹ 598.55 |
Bulk discount will be automatically applied during checkout based on quantity.
