Texas Instruments TPS79601DCQR Adjustable LDO Voltage Regulator 2.7 V to 5.5 250 mV Drop 1.225 / 1 A out SOT-223-6

The TPS79601DCQR is a low-dropout (LDO) low-power Linear Voltage Regulator features high power-supply rejection ratio (PSRR), ultralow-noise, fast start-up and excellent line and load transient responses. The device is stable with a small 1µF ceramic capacitor on the output. It uses an advanced, proprietary BiCMOS fabrication process to yield extremely low dropout voltages. The device achieves fast start-up times while consuming very low quiescent current. Moreover, when the device is placed in standby mode, the supply current is reduced to less than 1µA. Applications with analog components that are noise sensitive, such as portable RF electronics, benefit from the high PSRR, low noise features and need fast response time. It combines the high performance required of many RF and precision analog applications with low current consumption. High PSRR is provided by a high-gain, high-bandwidth error loop with good supply rejection at very low headroom (VIN - VOUT).

• Excellent load and line transient response
• 50µs Fast start-up time
• Noise-reduction pin is provided to bypass
• Quick-start circuit quickly charges the capacitor at start-up
• Green product and no Sb/Br

Applications

RF Communications, Signal Processing, Audio, Consumer Electronics, Communications & Networking, Portable Devices

Other details

Brand	TEXAS INSTRUMENTS
Part Number	TPS79601DCQR
Quantity	Each (Supplied on Cut Tape)
