Description
The LP3964ES-3.3/NOPB is a 3.3V fixed output fast ultra-low-dropout (LDO) Linear Regulator operate from a 2.5 to 7V input supply. This device respond very fast to step changes in load which makes them suitable for low-voltage microprocessor applications. The device is developed on a CMOS process which allows low quiescent current operation independent of output load current, as well as operation under extremely low-dropout (LDO) conditions. The dropout voltage is typically 24mV at 80mA load current and 240mV at 800mA load current.
- Low ground pin current
- Load regulation of 0.02%
- 15µA Quiescent current in shutdown mode
- ±1.5% Output voltage accuracy
- Sense option improves better load regulation
- Extremely low output capacitor requirements
- Overtemperature and overcurrent protection
Industrial, Power Management, Portable Devices
Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | LP3964ES-3.3/NOPB |
| Quantity | Each |
