| ₹ 376.4 includes GST and import duties. | |
| B2B customers can avail ₹ 57.4 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The LMR14206XMK/NOPB is a PWM DC/DC Buck (Step-down) Voltage Regulator with a wide input range from 4.5 to 42V, they are suitable for a wide range of applications such as power conditioning from unregulated sources. They feature a low RDSON (0.9R typical) internal switch for maximum efficiency (85% typical). Operating frequency is fixed at 1.25MHz allowing the use of small external components while still being able to have low output voltage ripple. Soft-start can be implemented using the shutdown pin with an external RC circuit allowing the user to tailor the soft-start time to a specific application. The LMR14206 is optimized for up to 600mA load current with a 0.765V nominal feedback voltage. Additional features include thermal shutdown, VIN under-voltage lockout and gate drive under-voltage lockout.
- 0.765 to 34V Output voltage range
- 1.25MHz Switching frequency
- 16µA Typical low shutdown IQ
- Short-circuit protection
- Internally compensated
- Soft-start function
- Tight accuracy for powering digital ICs
- Extremely easy to use
- Green product and no Sb/Br
Power Management, Industrial, Metering, Portable Devices
Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | LMR14206XMK/NOPB |
| Quantity | Each (Supplied on Cut Tape) |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 368.87 |
| 3-5 | ₹ 365.11 |
| 5-10 | ₹ 357.58 |
| 10+ | ₹ 350.05 |
Bulk discount will be automatically applied during checkout based on quantity.
