TerraMaster D5-THUNDERBOLT 3 Overview
-
1Description
-
2High Capacity
-
3Professional-Grade Speed
-
4Multi-Display Support
Add up to 80TB of high-speed RAID storage to your professional video editing setup with the D5 Thunderbolt 3 5-Bay RAID Enclosure from Terra-Master. Designed for 4K video editing and streaming, the enclosure supports up to five 2.5" and 3.5" SATA drives in hardware-controlled RAID 0, 1, 5, 10, Single Disk, and JBOD configuration with a maximum throughput of up to 1035 MB/s MB/s in RAID 0 over your Thunderbolt 3 connection. You can expand your capacity further by daisy chaining up to six compatible devices together using the second Thunderbolt 3 port. Featuring two built-in 80mm temperature-controlled smart fans, this portable Windows and Mac-compatible aluminum desktop enclosure is designed for optimal heat dissipation during long video editing projects. Additionally, a DisplayPort interface is available for connecting external 4K monitors directly to the enclosure for large projects and efficient multitasking. The D5 Thunderbolt 3 supports up to three displays simultaneously.
The D5 Thunderbolt 3 supports up to five 2.5" and 3.5" drives for a maximum capacity of 80TB. Up to six Thunderbolt 3 devices can be daisy chained together.
The high-speed RAID enclosure transfers data at up to 1035 MB/s in RAID 0 with a write speed of up to 850 MB/s over your 40 GB/s Thunderbolt 3 connection. Speeds of up to 1400 MB/s can be achieved in RAID 5.
Up to three displays can be connected to the D5 Thunderbolt 3 through its DisplayPort and Thunderbolt 3 ports.
In the Box
- TerraMaster D5 Thunderbolt 3 5-Bay RAID Enclosure
- Power Adapter
- Power Cord
- Thunderbolt 3 Cable
- Screw Pack
Table of Contents
- Description
- High Capacity
- Professional-Grade Speed
- Multi-Display Support
TerraMaster D5-THUNDERBOLT 3 Specs
General
| Number of Bays |
5 x 2.5"/3.5" |
| I/O |
2 x USB-C (Thunderbolt 3 (40 Gb/s))
1 x DisplayPort (DisplayPort 1.2) |
| Compatible Drive Interface |
SATA |
| Maximum Filled Capacity |
80 TB |
| Form Factor |
Desktop |
| RAID |
RAID 0, 1, 10, 5, JBOD, Single |
| Hot-Swap Support |
Yes |
| Transfer Rates |
1035 MB/s (Read in RAID 0)
850 MB/s (Write in RAID 0) |
Electrical
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Power Source |
AC Adapter |
| Power Consumption |
76.8 W |
| PSU Wattage |
1 x 120 W |
Environmental
| Operating Temperature |
41 to 104°F / 5 to 40°C |
| Operating Humidity |
5 to 95% |
| Storage Temperature |
-4 to 140°F / -20 to 60°C |
Physical
| Status Monitoring |
None |
| Cooling |
2 x 80 mm Fans |
| Noise Level |
19.8 dBA |
| Material of Construction |
Aluminum |
| Dimensions |
8.86 x 8.94 x 6.93" / 225 x 227 x 176 mm |
| Weight |
5.1 lb / 2.3 kg |
Packaging Info
| Package Weight |
7.815 lb |
| Box Dimensions (LxWxH) |
11.8 x 10.9 x 8.3" |
