This is a Power Inductor (SMD), 10 µH, 2.5 A, 3.1 A, VLS-EX series, 5mm x 5mm x 4.5mm, Wirewound product from TDK with the model number VLS5045EX-100M
Product details
| Inductance |
10µH |
| RMS Current (Irms) |
2.5A |
| Saturation Current (Isat) |
3.1A |
| Product Range |
VLS-EX series |
| Power Inductor Case |
5mm x 5mm x 4.5mm |
| Inductor Construction |
Wirewound |
| DC Resistance Max |
0.061ohm |
| Inductance Tolerance |
± 20% |
| Packaging |
Cut Tape |
Other details
| Brand |
TDK |
| Part Number |
VLS5045EX-100M |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
