| ₹ 6985.54 includes GST and import duties. | |
| B2B customers can avail ₹ 1065.29 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
UHV-2A is an ultra high voltage ceramic capacitor for high voltage power supplies/lasers (for medical devices, lithography, industrial analysers).
- Capacitance value is 2500pF with ±10% tolerance
- Rated voltage is 20KVDC
- Withstanding voltage is 30KVDC [1min. insulating liquid]
- Dissipation factor is 0.1% maximum
- 10,000Mohm minimum insulation resistance
- Low ESR, low loss and low distortion factor
- Moulded type metal screw terminals for easy mounting
- Uses high-reliability mould resin
- Operating temperature range from -30 to +85°C
Product details
Other details
| Brand | TDK |
| Part Number | UHV-2A |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 6845.83 |
| 3-5 | ₹ 6775.97 |
| 5-10 | ₹ 6636.26 |
| 10+ | ₹ 6496.55 |
Bulk discount will be automatically applied during checkout based on quantity.
