Description
This is a Power Inductor (SMD), 2.2 µH, 14.2 A, Shielded, 8.3 A, SPM-HZ Series, 7.1mm x 6.5mm x 5mm product from TDK with the model number SPM6550T-2R2M-HZ
Product details
| Inductance | 2.2µH |
| RMS Current (Irms) | 14.2A |
| Inductor Construction | Shielded |
| Saturation Current (Isat) | 8.3A |
| Product Range | SPM-HZ Series |
| Power Inductor Case | 7.1mm x 6.5mm x 5mm |
| DC Resistance Max | 0.0107ohm |
| Inductance Tolerance | ± 20% |
Other details
| Brand | TDK |
| Part Number | SPM6550T-2R2M-HZ |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
