| ₹ 155.14 includes GST and import duties. | |
| B2B customers can avail ₹ 23.66 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
This is a Power Inductor (SMD), 5.6 µH, 4.5 A, Shielded, 3.6 A, SPM-HZ Series, 5.2mm x 5mm x 3mm product from TDK with the model number SPM5030T-5R6M-HZ
Product details
| Inductance | 5.6µH |
| RMS Current (Irms) | 4.5A |
| Inductor Construction | Shielded |
| Saturation Current (Isat) | 3.6A |
| Product Range | SPM-HZ Series |
| Power Inductor Case | 5.2mm x 5mm x 3mm |
| DC Resistance Max | 0.0739ohm |
| Inductance Tolerance | ± 20% |
Other details
| Brand | TDK |
| Part Number | SPM5030T-5R6M-HZ |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 152.04 |
| 3-5 | ₹ 150.49 |
| 5-10 | ₹ 147.38 |
| 10+ | ₹ 144.28 |
Bulk discount will be automatically applied during checkout based on quantity.
