Description
This is an externally driven surface mount magnetic buzzer transducer.
Product Overview
This is an externally driven surface mount magnetic buzzer transducer.
Features & Specs
- Driver Circuitry: Transducer, Externally Driven
- Input Type: Zero-Peak Signal
- Voltage - Rated: 3.6V
- Voltage - Range: 2.5 ~ 4.5V
- Frequency: 2.73kHz
- Technology: Magnetic
- Operating Mode: Single Tone
- Sound Pressure Level (SPL): 83dB @ 3.6V, 10cm
- Current - Supply: 110mA
- Port Location: Side
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Termination: Solder Pads
- Size / Dimension: 0.354" Diameter (9.00mm)
- Height - Seated (Max): 0.106" (2.70mm)
