Description
Product Overview
The 4614-6000 is a 14-way 0.100 x 0.100-inch Wire to Board Connector for 0.050-inch pitch cable, with gold-plated phosphor bronze contacts and IDC/IDT termination. This 4600 series wiremount plug/connector is glass filled polyester (PBT) insulated, shrouded to protect against physical and chemical pin damage. This wire to board connector has open end cover, military (with 3518 polarizing key) and centerbump polarization for 14-contacts with mounting flange.
- Grey colour
- Accepts flat cable or discrete wire
- UL94V-0 Flammability rating
- 1A Current rating
- <gt/>1 x 10⁹Ω at 500VDC Insulation resistance
Applications
Industrial
Product details
| IDC Connector Type | IDC Plug |
| Pitch Spacing | 2.54mm |
| No. of Contacts | 14Contacts |
| Contact Material | Copper Alloy |
| Product Range | 4600 Series |
| Contact Gender | Male |
| No. of Rows | 2 Row |
| Connector Mounting | Cable Mount |
| Contact Plating | Gold Plated Contacts |
| SVHC | No SVHC (15-Jan-2018) |
Other details
| Brand | 3M |
| Part Number | 4614-6000 |
| Quantity | Each |
| Technical Data Sheet (827.71KB) EN | View or download |
| Product Change Notice (233.53KB) EN | View or download |
