| ₹ 1416.57 includes GST and import duties. | |
| B2B customers can avail ₹ 216.03 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
The D2VW series sealed miniature Basic Switch, use of epoxy resin assures stable sealing, making this switch ideal for places subject to water spray or excessive dust. V-series internal mechanism assures high precision and durability. The mounting is the same as of the V models. Monoblock construction assures high sealing capability and is ideal for applications where water spray or dust is prevalent. Pin plunger, short hinge lever, hinge lever, long hinge lever, short hinge roller lever, hinge roller lever and simulated roller lever actuator available. It is ideal for automobiles and large-scale home appliances, which require high environmental resistance.
- SPDT, SPST-NC and SPST-NO Contact form
- Solder and moulded lead-wire terminals available
- Watertight switch meets IP67 requirements (excluding the terminals on terminal models)
- IP67 Protection rating
Applications
Industrial
Product details
| Microswitch Type | Snap Action |
| Contact Configuration | SPDT |
| Contact Current Max | 5A |
| Product Range | D2VW Series |
| Operating Force Max | 0.59N |
| Microswitch Actuator | Long Lever |
| Switch Terminals | Solder |
| Contact Voltage DC Nom | 30V |
| Contact Voltage AC Nom | 250V |
| SVHC | No SVHC (17-Dec-2014) |
Other details
| Brand | ARATAS |
| Part Number | D2VW-5L1B-1 |
| Quantity | Each |
| Technical Data Sheet (1.14MB) EN | View or download |
| Product Change Notice (704.23KB) EN | View or download |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1388.24 |
| 3-5 | ₹ 1374.07 |
| 5-10 | ₹ 1345.74 |
| 10+ | ₹ 1317.41 |
Bulk discount will be automatically applied during checkout based on quantity.
