Product Overview
NICHICON UVY1H102MHD1TO Electrolytic Capacitor, 1000 µF, 50 V, ± 20%, Radial Leaded, 1000 hours @ 105°C, Polar
Product details
| Capacitance |
1000µF |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
1000 hours @ 105°C |
| Capacitor Case / Package |
Can |
| Product Diameter |
12.5mm |
| Product Width |
- |
| Product Range |
UVY Series |
| Ripple Current |
950mA |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
| Voltage(DC) |
50V |
| Capacitor Terminals |
Radial Leaded |
| Polarity |
Polar |
| Lead Spacing |
5mm |
| Product Length |
- |
| Product Height |
25mm |
| ESR |
- |
| Operating Temperature Min |
-55°C |
| Qualification |
- |
Other details
| Brand |
NICHICON |
| Part Number |
UVY1H102MHD1TO |
| Quantity |
Each |
| Technical Data Sheet (588.75KB) EN |
View or download |
