Product Overview
NICHICON UHW1V102MHD Electrolytic Capacitor, 1000 µF, 35 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar
Product details
| Capacitance |
1000µF |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
10000 hours @ 105°C |
| Capacitor Case / Package |
Can |
| Product Diameter |
12.5mm |
| Product Width |
- |
| Product Range |
UHW Series |
| Ripple Current |
2.6A |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
| Voltage(DC) |
35V |
| Capacitor Terminals |
Radial Leaded |
| Polarity |
Polar |
| Lead Spacing |
5mm |
| Product Length |
- |
| Product Height |
20mm |
| ESR |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
Other details
| Brand |
NICHICON |
| Part Number |
UHW1V102MHD |
| Quantity |
Each |
| Technical Data Sheet (761.57KB) EN |
View or download |
