Product Overview
NICHICON UCS2W680MHD Electrolytic Capacitor, 68 µF, 450 V, ± 20%, Radial Leaded, 1000 hours @ 105°C, Polar
Product details
| Capacitance |
68µF |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
1000 hours @ 105°C |
| Capacitor Case / Package |
Can |
| Product Diameter |
18mm |
| Product Width |
- |
| Product Range |
UCS Series |
| Ripple Current |
1.575A |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
| Voltage(DC) |
450V |
| Capacitor Terminals |
Radial Leaded |
| Polarity |
Polar |
| Lead Spacing |
7.5mm |
| Product Length |
- |
| Product Height |
31.5mm |
| ESR |
- |
| Operating Temperature Min |
-25°C |
| Qualification |
- |
Other details
| Brand |
NICHICON |
| Part Number |
UCS2W680MHD |
| Quantity |
Each |
| Technical Data Sheet (656.71KB) EN |
View or download |
