Product Overview
The WAGO 2585-547 relay module is a DIN rail mountable interface relay designed for reliable switching and isolation in industrial control and automation applications. Featuring a 115V AC input, two changeover (4CO/4PDT) contacts, and a 5A continuous switching current, this pre-assembled relay module combines a relay socket and elementary relay in a compact 31mm wide housing. A yellow LED status indicator provides clear visual indication of relay operation, while the integrated manual operation function allows convenient testing and commissioning.
- 115V AC coil voltage for standard industrial control systems
- 4 changeover contacts (4CO / 4PDT) provide flexible switching of multiple circuits
- 5A continuous current rating supports a wide range of control and switching applications
- Integrated manual operation lever enables easy testing and maintenance
- Yellow LED status indicator provides clear visual feedback of relay state
- DIN rail mounting allows quick installation in control cabinets and panels
- Relay socket and relay supplied as a complete assembly for reduced installation time
- Compact 31mm module width helps optimise panel space
Product details
| Contact Configuration |
4PDT |
| Contact Current |
5A |
| Relay Mounting |
DIN Rail |
| Contact Voltage VAC |
250V |
| Contact Voltage VDC |
30V |
| Coil Resistance |
- |
| Coil Voltage |
115V |
| Product Range |
WAGO - 2585 Series |
| Coil Type |
Non Latching |
| Relay Terminals |
Plug In |
| Contact Material |
Silver Tin Oxide |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
WAGO |
| Part Number |
2585-547 |
| Quantity |
Each |
| Technical Data Sheet (5.26MB) EN |
View or download |
