Product Overview
VISHAY MKP385E51010KPM2T0 Power Film Capacitor, Metallized PP, Radial Box - 2 Pin, 1 µF, ± 10%
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
1µF |
| Typical Applications |
Hybrid Electrical Vehicle, BMS, Snubbering, On-Board Inductive Charging, High Pulse And Frequency |
| Voltage(AC) |
350V |
| Humidity Rating |
GRADE III (Test Condition B) |
| Lead Spacing |
37.5mm |
| Peak Current |
180A |
| ESR |
0.007ohm |
| Product Length |
41.5mm |
| Product Height |
28.5mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
AEC-Q200 |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 10% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
1kV |
| Capacitor Terminals |
Radial Leaded |
| dv/dt Rating |
180V/µs |
| RMS Current (Irms) |
10.5A |
| Product Diameter |
- |
| Product Width |
15.7mm |
| Ripple Current |
- |
| Product Range |
MKP385e Series |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
VISHAY |
| Part Number |
MKP385E51010KPM2T0 |
| Quantity |
Each |
| Technical Data Sheet (253.01KB) EN |
View or download |
