Product Overview
ASB320PS48 is an ASB320 series complete, baseplate-cooled AC-DC power supply available in a compact, encapsulated brick format. Featuring built-in EMC filter, AC fuse and bulk storage capacitor, the ASB320 simplifies system design by providing a complete AC-DC power solution ready for installation into end applications. High efficiency and baseplate cooling enable efficient thermal management, supporting reliable operation in compact and sealed enclosures. Global ITE safety approvals, Class B emissions and a low profile rugged mechanical design make the ASB320 series an ideal solution to a wide range of applications including industrial automation, analytical instrumentation, test and measurement and communications equipment.
- Input voltage range from 90 to 264V AC
- Output voltage of 48V DC, output current of 6.66A
- 320W output power, 94% efficiency
- Output voltage trim ±5%
- Class B conducted & radiated emissions
- Over current, over voltage & over temperature protection
- -40°C to +90°C baseplate operating temperature
- 116.8 x 85.0 x 19.7mm (4.60” x 3.35” x 0.78”) fully encapsulated brick package
- 3 year warranty
Product details
| Power Supply Applications |
ITE & Industrial |
| Output Power Max |
320W |
| Output Current - Output 1 |
6.66A |
| Output Current - Output 2 |
- |
| Output Current - Output 3 |
- |
| Input Voltage VAC |
90V AC to 264V AC |
| Height |
19.7mm |
| Product Range |
ASB320 Series |
| No. of Outputs |
1 Output |
| Output Voltage - Output 1 |
48V |
| Output Voltage - Output 2 |
- |
| Output Voltage - Output 3 |
- |
| Power Supply Output Type |
Fixed |
| Width |
85mm |
| Depth |
116.8mm |
| SVHC |
No SVHC (15-Jan-2018) |
Other details
| Brand |
XP POWER |
| Part Number |
ASB320PS48 |
| Quantity |
Each |
| Technical Data Sheet (923.29KB) EN |
View or download |
