Product Overview
ENDRESS+HAUSER UTC30-AAD1PDBBAA1ABAAAS9Y+RBSASPSTS1TATS Pressure Transmitter, Gauge, Female Threaded, -1 bar, 10 bar, M10 x 1
Product details
| Pressure Type |
Gauge |
| Operating Pressure Min |
-1bar |
| Pressure Port Size |
M10 x 1 |
| Supply Voltage Min |
2.9VDC |
| Media Type |
Gas, Liquid |
| Sensor Output Type |
Digital, Ratiometric |
| Operating Temperature Min |
-20°C |
| Product Range |
Ceracore UTC30 Series |
| Pressure Port Type |
Female Threaded |
| Operating Pressure Max |
10bar |
| Transducer Connection / Termination |
2x5 Pin Female Header Connector |
| Supply Voltage Max |
5.5VDC |
| Output Interface |
SPI, UART |
| Housing Material |
316L Stainless Steel |
| Operating Temperature Max |
80°C |
Other details
| Brand |
ENDRESS+HAUSER |
| Part Number |
UTC30-AAD1PDBBAA1ABAAAS9Y+RBSASPSTS1TATS |
| Quantity |
Each |
| Technical Data Sheet (807.49KB) EN |
View or download |
