Product Overview
Also known as
4AUPBU4200M18J
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
2µF |
| Typical Applications |
DC Link |
| Voltage(AC) |
- |
| Humidity Rating |
GRADE III (Test Condition B) |
| Lead Spacing |
27.5mm |
| Peak Current |
180A |
| ESR |
0.0151ohm |
| Product Length |
32mm |
| Product Height |
30mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-55°C |
| Qualification |
AEC-Q200 |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
1.2kV |
| Capacitor Terminals |
Radial Leaded |
| dv/dt Rating |
90V/µs |
| RMS Current (Irms) |
7.7A |
| Product Diameter |
- |
| Product Width |
16mm |
| Ripple Current |
- |
| Product Range |
C4AU Series |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
KEMET |
| Part Number |
C4AUPBU4200M18J |
| Quantity |
Each |
