Product Overview
OT-FIT-150/220-240/1A0-D-NFC-IND-L is a linear LED power solution, with flexible and future-proof current setting via NFC and LT2. A high quality of light is possible thanks to <1% output ripple current and high surge protection. The OT FIT has an integrated inrush current limiter as well as a wide operating temperature range of -40 to +65 degrees. Enabling users to fulfil safety requirements due to overload, overtemperature and hot plug protection.
- 0Hz/50Hz/60Hz line frequency
- Versatile scope of application due to output power range of up to 300 W
- Available with output current range up to 1,600mA
- Supply voltage range from 220V to 240V
- Constant lumen output (CLO)
- Non-isolated drivers
- Flexible and future-proof current setting via NFC and LT2
- Lifetime up to 100,000 h (temperature at T c = 75 °C, max. 10 % failure rate)
- Wide operating temperature range: -40…+65°C
Product details
| Power Supply Applications |
LED Lighting |
| Output Voltage Max |
300V |
| LED Driver Mode |
Constant Current |
| Input Voltage Max |
264V |
| SVHC |
No SVHC (04-Feb-2026) |
| Output Power Max |
150W |
| Output Current |
1A |
| Input Voltage Min |
198V |
| Product Range |
OPTOTRONIC FIT D NFC IND L Series |
Other details
| Brand |
INVENTRONICS |
| Part Number |
OT-FIT-150/220-240/1A0-D-NFC-IND-L |
| Quantity |
Each |
| Technical Data Sheet (462.63KB) EN |
View or download |
