Product Overview
ARATAS G9KD-1A1B DC24 Power Relay, SPST-NO, SPST-NC, 24 VDC, 150 A, G9KD Series, Through Hole, Non Latching
Product details
| Contact Configuration |
SPST-NO, SPST-NC |
| Contact Current |
150A |
| Relay Mounting |
Through Hole |
| Contact Voltage VAC |
- |
| Contact Voltage VDC |
1.5kV |
| Coil Resistance |
115ohm |
| Coil Voltage |
24VDC |
| Product Range |
G9KD Series |
| Coil Type |
Non Latching |
| Relay Terminals |
PC Pin |
| Contact Material |
Silver Alloy |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
ARATAS |
| Part Number |
G9KD-1A1B DC24 |
| Quantity |
Each |
| Technical Data Sheet (1.76MB) EN |
View or download |
