Product Overview
Also known as
5114N/2-060
Product details
| Nominal Rated Voltage AC |
24V |
| Fan Frame Size |
135mm |
| Bearing Type |
Ball Bearing |
| Noise Rating |
48dBA |
| Rated Speed |
2900rpm |
| Current Rating |
395mA |
| Air Flow - m3/min |
4.33m³/min |
| Operating Voltage Max |
- |
| Product Range |
- |
| Fan Frame Type |
Square |
| External Depth |
38mm |
| Air Flow - CFM |
153CFM |
| Power Rating |
9.5W |
| Power Connection Type |
3 Lead Wires, Tachometer |
| IP Rating |
- |
| Operating Voltage Min |
- |
| Static Pressure |
122Pa |
| SVHC |
No SVHC (04-Feb-2026) |
