Product Overview
SANYO DENKI 9RA0924P1G001 DC Axial Fan, 24 V, Square, 92 mm, 38 mm, Precision Ball Bearing, 105 CFM
Product details
| Supply Voltage VDC |
24V |
| Fan Frame Size |
92mm |
| Bearing Type |
Precision Ball Bearing |
| Noise Rating |
47dBA |
| Rated Speed |
5800rpm |
| Current Rating |
480mA |
| Air Flow - m3/min |
2.97m³/min |
| Product Range |
San Ace 92 9RA Series |
| Fan Frame Type |
Square |
| External Depth |
38mm |
| Air Flow - CFM |
105CFM |
| Power Rating |
11.5W |
| Power Connection Type |
4 Lead Wires, Pulse Sensor, PWM Control |
| IP Rating |
- |
| Static Pressure |
158Pa |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
SANYO DENKI |
| Part Number |
9RA0924P1G001 |
| Quantity |
Each |
| Technical Data Sheet (760.31KB) EN |
View or download |
