Product Overview
SANYO DENKI 9RA0924P1J001 DC Axial Fan, 24 V, Square, 92 mm, 38 mm, Precision Ball Bearing, 116 CFM
Product details
| Supply Voltage VDC |
24V |
| Fan Frame Size |
92mm |
| Bearing Type |
Precision Ball Bearing |
| Noise Rating |
50dBA |
| Rated Speed |
6400rpm |
| Current Rating |
620mA |
| Air Flow - m3/min |
3.28m³/min |
| Product Range |
San Ace 92 9RA Series |
| Fan Frame Type |
Square |
| External Depth |
38mm |
| Air Flow - CFM |
116CFM |
| Power Rating |
14.9W |
| Power Connection Type |
4 Lead Wires, Pulse Sensor, PWM Control |
| IP Rating |
- |
| Static Pressure |
192Pa |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
SANYO DENKI |
| Part Number |
9RA0924P1J001 |
| Quantity |
Each |
| Technical Data Sheet (760.31KB) EN |
View or download |
