Product Overview
WAGO 2616-1108/020-000 Wire-To-Board Terminal Block, Grey, 10 mm, 8 Ways, 18 AWG, 4 AWG, 16 mm², Push In
Product details
| Pitch Spacing |
10mm |
| Wire Size AWG Min |
18AWG |
| Conductor Area CSA |
16mm² |
| Rated Current |
76A |
| Block Orientation |
Through Hole Right Angle |
| SVHC |
No SVHC (04-Feb-2026) |
| No. of Positions |
8Ways |
| Wire Size AWG Max |
4AWG |
| Wire Connection Method |
Push In |
| Rated Voltage |
1kV |
| Product Range |
2616 Series |
Other details
| Brand |
WAGO |
| Part Number |
2616-1108/020-000 |
| Quantity |
Each |
