Product Overview
STMICROELECTRONICS STM32H523CCT7 ARM MCU, STM32 Family STM32H5 Series Microprocessors, ARM Cortex-M33F, 32 bit, 250 MHz, 256 KB
Product details
| Product Range |
STM32 Family STM32H5 Series Microprocessors |
| Data Bus Width |
32 bit |
| Program Memory Size |
256KB |
| IC Case / Package |
LQFP |
| Interfaces |
FDCAN, I2C, I2S, I3C, LPUART, SDMMC, SPI, UART, UCPD, USART, USB |
| ADC Channels |
10Channels |
| Supply Voltage Min |
1.71V |
| Operating Temperature Min |
-40°C |
| IC Mounting |
Surface Mount |
| MCU Series |
STM32H5 |
| SVHC |
No SVHC (04-Feb-2026) |
| Device Core |
ARM Cortex-M33F |
| Operating Frequency Max |
250MHz |
| No. of Pins |
48Pins |
| No. of I/O's |
35I/O's |
| RAM Memory Size |
272KB |
| ADC Resolution |
12Bit |
| Supply Voltage Max |
3.6V |
| Operating Temperature Max |
105°C |
| MCU Family |
STM32 |
| Qualification |
- |
Other details
| Brand |
STMICROELECTRONICS |
| Part Number |
STM32H523CCT7 |
| Quantity |
Each |
| Product Change Notice (296.66KB) EN |
View or download |
| Technical Data Sheet (4.55MB) EN |
View or download |
