Product Overview
VISHAY MKP1848S52010JK2A Power Film Capacitor, Metallized PP, Radial Box - 2 Pin, 2 µF, ± 5%, DC Link, Through Hole
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
2µF |
| Typical Applications |
DC Link |
| Voltage(AC) |
- |
| Humidity Rating |
GRADE II (Test Condition A) |
| Lead Spacing |
27.5mm |
| Peak Current |
100A |
| ESR |
0.016ohm |
| Product Length |
31.5mm |
| Product Height |
12mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
1kV |
| Capacitor Terminals |
PC Pin |
| dv/dt Rating |
50V/µs |
| RMS Current (Irms) |
3A |
| Product Diameter |
- |
| Product Width |
24mm |
| Ripple Current |
- |
| Product Range |
MKP1848S Series |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
