Product Overview
VISHAY MKP1848620924Y5 Power Film Capacitor, Metallized PP, Radial Box - 4 Pin, 20 µF, ± 5%, DC Link, Through Hole
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
20µF |
| Typical Applications |
DC Link |
| Voltage(AC) |
- |
| Humidity Rating |
GRADE II (Test Condition A) |
| Lead Spacing |
52.5mm |
| Peak Current |
480A |
| ESR |
0.0075ohm |
| Product Length |
57.5mm |
| Product Height |
50mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
AEC-Q200 |
| Capacitor Case / Package |
Radial Box - 4 Pin |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
1.2kV |
| Capacitor Terminals |
PC Pin |
| dv/dt Rating |
24V/µs |
| RMS Current (Irms) |
14A |
| Product Diameter |
- |
| Product Width |
35mm |
| Ripple Current |
- |
| Product Range |
MKP1848 Series |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
