Product Overview
VISHAY MKP1848612454K2 Power Film Capacitor, Metallized PP, Radial Box - 2 Pin, 12 µF, ± 5%, DC Link, Through Hole
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
12µF |
| Typical Applications |
DC Link |
| Voltage(AC) |
- |
| Humidity Rating |
GRADE II (Test Condition A) |
| Lead Spacing |
27.5mm |
| Peak Current |
900A |
| ESR |
0.007ohm |
| Product Length |
32mm |
| Product Height |
31mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
AEC-Q200 |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
450V |
| Capacitor Terminals |
PC Pin |
| dv/dt Rating |
75V/µs |
| RMS Current (Irms) |
10A |
| Product Diameter |
- |
| Product Width |
21mm |
| Ripple Current |
- |
| Product Range |
MKP1848 Series |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
