SAME SKY CDM805-03A-FP-F011-67 Sensor Connector, CDM805 Series, M8, Female, 3 Positions, PCB Pin, Straight Panel Mount
Product details
| Product Range |
CDM805 Series |
| Sensor Connector Gender |
Female |
| Sensor Contact Type |
PCB Pin |
| IP / NEMA Rating |
IP67 |
| Connector Body Material |
Nylon 6.6 (Polyamide 6.6) Body |
| Contact Plating |
Gold |
| Voltage Rating |
60V |
| Sensor Connector Size |
M8 |
| No. of Positions |
3 Positions |
| Sensor Connector Mounting |
Straight Panel Mount |
| Connector Coding |
A Coded |
| Contact Material |
Brass |
| Current Rating |
3A |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
SAME SKY |
| Part Number |
CDM805-03A-FP-F011-67 |
| Quantity |
Each |
| Technical Data Sheet (69.00B) EN |
View or download |
