Product Overview
SAME SKY TB007-508-11GR Wire-To-Board Terminal Block, Green, 5.08 mm, 11 Ways, 24 AWG, 12 AWG, 2.5 mm², Screw
Product details
| Pitch Spacing |
5.08mm |
| Wire Size AWG Min |
24AWG |
| Conductor Area CSA |
2.5mm² |
| Rated Current |
18A |
| Block Orientation |
Through Hole Right Angle |
| SVHC |
No SVHC (04-Feb-2026) |
| No. of Positions |
11Ways |
| Wire Size AWG Max |
12AWG |
| Wire Connection Method |
Screw |
| Rated Voltage |
250V |
| Product Range |
TB007-508 Series |
Other details
| Brand |
SAME SKY |
| Part Number |
TB007-508-11GR |
| Quantity |
Each |
| Technical Data Sheet (72.00B) EN |
View or download |
