Product Overview
SAME SKY CFM-A238BF-270-651-22 DC Axial Fan, 24 V, Square, 120 mm, 38 mm, Ball, 230.2 CFM
Product details
| Supply Voltage VDC |
24V |
| Fan Frame Size |
120mm |
| Bearing Type |
Ball |
| Noise Rating |
65.1dBA |
| Rated Speed |
7000rpm |
| Current Rating |
2.54A |
| Air Flow - m3/min |
- |
| Product Range |
CFM-120BF Series |
| Fan Frame Type |
Square |
| External Depth |
38mm |
| Air Flow - CFM |
230.2CFM |
| Power Rating |
40.56W |
| Power Connection Type |
4 Lead Wires |
| IP Rating |
- |
| Static Pressure |
1.65Inch-H2O |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
SAME SKY |
| Part Number |
CFM-A238BF-270-651-22 |
| Quantity |
Each |
| Technical Data Sheet (81.00B) EN |
View or download |
